Bariatric Rise and Recliners

Bariatric Seating solutions tailored to the user’s requirements with features that deliver deep comfort and enhanced postural control

Fabric Shown:
Panvelle stretch plain indigo with Blue Vapour permeable inner

Designed for comfort and pressure management our Bariatric range comes with four mechanism choices, a wide range of weight limits, up to 445 Kg (70 stone) all with a waterfall back design which is useful for those with mild kyphosis, scoliosis and reduced muscle mass and a choice of interchangeable seat cushions with different pressure management options.

This rise and recline chair comes with a multitude of optional extras.

  • Choose from a large choice of fabrics and colours
  • Made to measure
  • Dual or Single motors available
  • Accessorise your chair with various options
  • Choose your comfort seating

Repose offer a wide range of chair sizes from small to large ensuring both quality and comfort.

Available as an Express Chair, click our express van to find out more!

The Bariatric plus sized chairs are suitable for either a health or home environment.  They offer clients and carers movement options that support good posture, pressure management and independent living. The range of mechanisms is ideal for those clients:

  • who are unable to independently shift their weight either in a reclined or seated position.
  • with poor skin integrity where there is a high risk of skin breakdown.
  • with complex needs that require carer support to change position without putting their own health at risk whilst carrying out positional changes.

On some mechanisms the back recline works independently of the leg rest enabling a wide range of relaxing positions, from sitting upright and raising the leg rest to relieve tired legs to a fully reclined resting position. The leg elevation can support reduction in oedema and fluid retention. This reduced fluid in the lower limbs allows a user to maintain their standing and walking abilities. The rise position on some mechanisms supports standing, enabling the person to walk away more easily.

The three waterfall cushions are fixed on some models and on others are removable as standard.  With all removable back cushions they can be repositioned to change the seating position to aid posture.  The waterfall cushion can be useful for those with mild kyphosis, scoliosis and reduced muscle mass on their back.

The waterfall back is complemented by a choice of five different seat cushions all with different pressure management qualities.  Choose the one that best suits the postural and pressure management conditions of the client.

These chairs can also be used as part of a 24-hour postural care programme to reduce the risk of skin breakdown and its features also ensure that a user can be repositioned to allow for optional occupational performance, thus allowing an individual to engage in activities they want to do.

Environments:

healthcare 2 Repose Furniture Bariatric nursing and care home Repose Furniture Bariatric home Repose Furniture Bariatric

Bariatric00 Repose Furniture Bariatric



For more information on seating posture and assessment please see our downloadable Clinical Posture Guide in the Brochure Section.

The Bariatric range comes with the following key features as standard. There is the option to purchase additional features and these are detailed in the Optional Accessories Section.

For an overview of Bariatric seating assessment see our downloadable PDF in the Brochure Section.  Here you will also be able to download a copy of our Clinical Posture Guide.

Mechanism

The Bariatric range comes with the option of choosing one of the following mechanisms:

  • Single motor 3 way
  • Single motor tilt in space
  • Dual motor tilt in space
  • Standard dual motor

They all of which have different features which are described in more detail In the Mechanisms Section, including video clips.

Always ensure that the weight limits are checked for the client and particularly for conditions such as Lymphedema or Oedema.

Bariatric02

Three Tier Waterfall Back Cushion

Depending on the model chosen there will be either a fixed or removable three-tiered waterfall back cushion.

With the three removable and replaceable waterfall cushions they can be repositioned enabling the user to be seated and their posture supported correctly to meet their individual needs. The comfort and postural options are further enhanced with the ability to adjust the firmness of each individual cushion by adding or taking away fibres.

Covers can also be removed for cleaning or replacement. See Back Cushion Section for details on this back cushion.

Bariatric Three Tier Waterfall Back Cushion

Back Blockers

On some of the models back blockers come as standard, on others they are available as an optional accessory.

At the back of the waterfall cushions, sleeves can be fitted to accommodate the blockers to provide additional postural support. The position of each back cushion can be adapted with blockers to adjust the shape and support for the specific needs of each user. Blockers are provided as standard.

Bari Back Blockers

Pressure Management Seat Cushions

There is a choice of 5 interchangeable seat cushions each with different pressure management features.  You can purchase one or more cushions to support the different needs of individuals who may use this chair.

Cushions and covers are removable for cleaning.  With all these seat cushions we recommend a fabric with four way stretch properties to aid reduction of shear and friction.  See Seat Cushion Section for details of the individual cushions.



Chaise Cover

The Bariatric chairs benefit from a single, full seat cover. This chaise reduces the risk of pressure areas developing due to pinch points and shear and friction when the chair reclines. Designed with a memory foam insert the chaise offers deep comfort.

The chaise cover and memory foam can be removed for cleaning and replacement. Optional memory foam or gel seating for added comfort and pressure management.



Arm Rest Design

There is a choice of three different styles of arm rest depending on the model chosen.  For further details see Optional Accessories Section.

  • Wide flat
  • Scroll
  • Wooden Knuckle


Handset Loop and Deep Side Pocket

These are positioned on the right-hand side of the chair.  If you want them on the left hand side of the chair please request this on ordering.



Heavy-duty Glides

These come as standard on all of the models.

Bariatric Guides

Bariatric Rise and Recliners Overall Weight Limits

The Bariatric Rise and Recliner has an overall weight limit range of between 222 Kg – 445 Kg (35 to 70 stone) depending on the model chosen.  The leg rest capacity will depend on the model chosen and can range from 57 Kg to 159 Kg (9 to 25 stone).

Seat Cushion Weight Limits

Certain pressure management seat cushion options have their own overall weight limits details of which can be found in the Seat Cushion Section. The maximum leg rest weight limit is unaffected by the seat cushion.

Important Dimensions

Mechanism Weight limit Seat height Seat width Seat depth
Single TIS 35 stone
222kg
18" - 20"
457 - 508mm
20" - 28"
508 - 711mm
18" - 21"
457 - 533mm
Single Non-wallhugger 35 stone
222kg
18" - 20"
457 - 508mm
24" - 28"
610 - 711mm
18" - 21"
457 - 533mm
Dual Standard 35 stone
222kg
16" - 17"
406 - 432mm
24" - 28"
610 - 711mm
18" - 21"
457 - 533mm
Dual Standard 40 stone
254kg
18" - 20"
457 - 508mm
24" - 32"
610 - 812mm
18" - 21"
457 - 533mm
Dual Standard 70 stone
444kg
19" - 20"
483 - 508mm
34" - 35"
864 - 889mm
21"
533mm

For 50 stone / 317kg - please see our Arden product

Please note that:

  • Depending on the seat cushion built into the chair the seat height may vary slightly from that shown above.

All our health fabrics are Waterproof, Anti-MRSA, Anti-bacterial, Anti-fungal, Crib 5 and bleach cleanable. All cushions and cushion covers are removable for cleaning purposes.

For our full range of fabrics please view our:

Fabric Options Page

Fabric Swatches 960

The Bariatric comes with a waterfall back cushion which is fixed on some models as standard and is removable and repositionable on others.

On the removable back cushion they can be repositioned enabling the user to be seated and their posture supported correctly to meet their individual needs. The comfort and postural options are further enhanced with the addition of the blockers that adjust the shape and support of the back cushions, and the ability to adjust the firmness of each individual cushion by adding or taking away fibres.  Covers can also be removed for cleaning or replacement.

This back style can be useful for those with mild kyphosis, scoliosis and reduced muscle mass on their back.

If you would like to find out about what back cushions are available on other healthcare chairs from the Repose range please contact the sales department on 01384 567401.

Removable Back Cushion

The waterfall back cushions are removable, to enable the cushions to be repositioned or replaced at a later stage.

They are supplied with back blockers to be placed in the sleeves position behind the top and middle waterfall cushions.  This will help to adjust the shape and support for the needs of each user.

Bariatric Three Tier Waterfall Back Cushion


Waterfall

Individual fibre filled waterfall cushions, each of which are fully adjustable to accommodate maximum postural support. The waterfall back can be useful for those with mild Kyphosis, Scoliosis and reduced muscle mass on their back.

2020 Waterfall WB Repose Furniture Bariatric

Removable Back Cushion

You can upgrade the back cushion to be removable, to enable the cushions to be repositioned or replaced at a later stage

spacer Repose Furniture Bariatric

Rimini Model Recline

The choice of materials in the seat cushion of your chair can make all the difference to your comfort and support. We offer the full range from soft and firm quality Reflex foam, to our specialist care cushions.

If you need a little more support from your seat cushion, perhaps if you sit for long periods in your chair, do consider our specialist seat cushions.

For ultimate comfort at the heart of your chair, we can also build in our Luxury Pocket Sprung Cushion. Designed with individual high tensile steel coil springs in individual pockets, the springs give consistent support throughout the life of the chair and lasting shape to the seat cushion.

Standard Comfort Seating

Specialist Seating

Sprung cushion

Please note: Pocket Sprung option is not available in chairs with seat widths over 22" or seat depths below 16". Pocket sprung seat is not compatible with Heat & Massage.

There is a choice of 5 detachable headrests all attached with a velcro tab.

If you would like to find out about what headrest cushions are available on other healthcare chairs from the Repose range please contact the sales department on 01384 567401.


Standard Arm Caps

Arm Cover Repose Furniture Bariatric

Full Length Arm Caps

Full length arm cover Repose Furniture Bariatric

Small Head Pillow

The small head pillow provides additional comfort for those who may require a softer surface to rest on whilst stopping hyper-extension at the neck when reclined or tilted.
Small head pillow Repose Furniture Bariatric

Head Roll

The head roll is useful to reduce depth for anyone with reduced neck extension or needing to keep their head in a neutral position for tasks such as eating or drinking whilst maximising comfort and reducing effort.
Head roll Repose Furniture Bariatric

Seat Cover

seat cover Repose Furniture Bariatric

Arm Upgrade – Wood Knuckles (light, medium or dark)

Wooden Knuckles Rec Repose Furniture Bariatric

The following features can be purchased to enhance the functionality of the chair.

High Wear Areas

The following covers, in matching fabric, can be purchased to protect high wear areas:

  • Full length arm covers
  • Head cover
  • Seat cover.

Full Length Arm Cover

Head Cover

Seat Cover


Headrests

There are five headrests to choose from, all of which come with a Velcro tab allowing them to fit over the top cushions.  For further details on each of these options please refer to the Headrest Section.

  • Head roll
  • Small head pillow
  • Small profile headrest
  • Large profile headrest
  • Midline headrest
Head Roll

Arm Rest Designs*

The Bariatric models can have a choice of three different arm rest styles as shown below. With the wide arm style there is the option to upgrade to a Memory foam or Coolform gel interior with a vapour permeable fabric.



Scroll

Scroll Arm

Wooden

Wooden Knuckle

Wide Flat

Wide Flat Arm

Heat and Massage Systems*

There is the option to choose either a heat only system or a heat and massage system.



Heat Only System

This system comes with two heat modules, one fitted into the seat of the chair and the other in a loose cushion heat pad that you can use behind your back, on your lap or to one side. The pads are controlled separately with an easy to use handset which has two temperature settings.

Bariatric Model


Heat and Massage System

The Relaxor helps soothe tired and aching muscles with gentle vibration and warmth. A separate handset controls different vibration zones built into the chair to massage upper back, lower back, upper and lower thighs and calves. Choose your own intensity and speed of each of the pairs of pads. The heat pad in the bottom lumbar of the back cushion completes the relaxing process, exactly what is needed at the end of the day.

Please note: It is recommended that you consult a healthcare professional or doctor if you suffer with a medical condition or have any medical device fitted (e.g. pacemaker) before purchasing this system.

Heat And Massage


Reading Lamp*

This built-in lamp brings the light to where it is most needed and can be set at three brightness levels.

This operated by the handset which operates your chair also.  The Reading lamp can be removed and stored away when not required

Lamp S


USB*

A USB charging point can be fitted to the chair to charge or operate items such as a mobile phone, tablet or ipad.

Usb Ports


Foot Rest Gel

For additional support for the foot-rest area gel can be added.



Safety Options*

For further details on the options below please refer to Safety Options Section.

  • Accupak rechargeable battery system
  • 20 Cycle back up system
  • Enclosure skirt


* Please note that some of these additional features will need to be fitted at the point of manufacture.

The Bariatric riser recliner chair is available with the following mechanisms:

  • Single Motor Tilt in Space – up to 35 stone (222kg)
  • Dual Motor Tilt in Space – up to 35 stone (222kg)
  • Standard Dual Motor – up to 70 stone (444kg)

The most important aspect to consider before purchasing any bariatric chair are the seating positions that are required to aid the conditions of the client and address any pressure and postural management needs.

The Bariatric is available with the following mechanisms. Please check the Sizes Section for all user weights and dimensions before selecting your chair.  For demonstrations of the mechanisms described below please watch the relevant videos.

If you would like to find out about what mechanisms are available on other healthcare chairs from the Repose range please contact the sales department on 01384 567401.


Single Tilt in Space/Dual Tilt in Space/Standard Dual Motor
DTIS and STIS (Common features)

The Tilt in Space movement features on both these mechanisms. It allows the seat to back angle to remain the same whilst the whole seating system is tilted backwards. This ensures that the angle of the hips, knees and ankles remain unaffected and the weight on the Ischial Tuberosities is reduced by redistributing the weight through the back. This constant angle also prevents shear and friction during movement.

This feature can also help when transferring someone in a sling as it can support better pelvic positioning by using gravity to position the user in the back of the chair in the optimal position.

Both these mechanisms have a rise position. As the chair rises the seat tilts forward slightly, transferring the weight to the knees whilst taking away the pressure from your hips thus allowing you to walk away more easily from the chair. The seat angle can be changed to provide further support by choosing the VAL Technology.

Dual Tilt In Space

Mutli C Air Dtis

Single Tilt In Space

Multi C Air Stis


DTIS (Only)

As well as the Tilt in Space and Rise functions, described above, the Dual Tilt in Space mechanism also features an independent backrest recline and independent leg rest movement:

  • The independent recline allows the user to maintain flexibility over their body’s position, particularly the amount of hip flexion, enabling them to maximise comfort as well as managing health needs.
  • The independent leg rest offers the user additional flexibility over positioning, allowing them to either use it in conjunction with the recline feature to create the optimal posture for their body shape.

Standard Dual Motor

The Standard Dual Motor comes with an independent backrest recline and independent leg rest enables a whole range of movements and positions to aid posture and pressure management. It also has a rise function for ease of standing from a seated position.

Standard Dual Motor

dual motor tilt in space Repose Furniture Bariatric
single motor tilt in space Repose Furniture Bariatric
standard dual motor Repose Furniture Bariatric

The Bariatric chairs come with the option to choose the following safety features:


Styleline Handset with On/Off Button

On some handsets you can choose to have an on/off emergency stop button. Please ask your supplier for the option available on your chair model.

Styleline handset with on off button Repose Furniture Bariatric

Accupak Rechargeable Battery System

The Accupak power pack enables you to use the chair away from a power supply. The battery provides an average of up to 100 adjustment cycles and will need recharging regularly to retain the quality of usage. It can be charged by simply plugging it in. The system sits out of sight under the chair and the charging outlet is built into the side of the chair.

Please note that the Accupak is not compatible with the Reading Lamp.

Full user instructions can be found in the user manual – please read these carefully before using the chair and Accupak. A copy of the manual can be found in the Brochures Section.

acc accupak 200 Repose Furniture Bariatric

20 Cycle Back Up Unit

This back up system comes as stand-alone unit that can carry out up to 20 chair adjustments. It should only be used as an emergency back-up system.

Full user instructions can be found in your user manual – please read these carefully before using the chair and the 20 cycle back up. A copy of the manual can be found in the Brochures Section.

acc bak 200 Repose Furniture Bariatric

Enclosure Skirt

The enclosure skirt hides the mechanism when the chair is either in the full rise or recline positions. This has been designed to stop small pets entering the mechanism whilst in the recline or rise positions.

enclosure kit Repose Furniture Bariatric

Below is a summary of our Standard two-year warranty terms and conditions.

There is also the option to upgrade to a five-year comprehensive care plan.

Standard Two-Year Warranty

Two years on mechanisms, frame, upholstery and electrics.

One year on air seat cushions and also on some additional accessories such as the Accupak, 20 Cycle Back up and Relaxor heat and massage systems.

Repose will repair or replace, at our discretion and free of charge to the original purchaser, any parts covered by this warranty and that on examination, are found to be defective in material and/or workmanship. The warranty is for parts and labour only. The product or parts requiring repair/replacement must be returned to Repose by you and you will be responsible for the costs of packaging, postage and any postal insurance.

Any products returned to Repose must be disinfected and should pose no health hazard.

For full details of the warranty including return of faulty products, exclusions etc. please see downloadable 2 year warranty document below.

2 Year Warranty Terms

Nail Varnish Spill

Spilt Tea


Upgrade to a Five-Year Warranty*

You can upgrade your standard warranty anytime within 14 days after delivery of the chair. You can upgrade to a unique five-year comprehensive care plan that includes:

  • Comprehensive cover for structural and accidental damage
  • Stain removal and repair at no extra cost to you
  • One call for advice and service
  • National network of professional technicians
  • Original value replacements

It truly offers real peace of mind, covering you against:

  • Structural damage to:
  • Accidental damage including:
  • Staining

For full details of the upgrade warranty please see the downloadable 5 year warranty document below.

5 Year Warranty Terms

Careplanhome

Wine & Cork

* non-commercial only
